LTC6409 的典型應用 - 10GHz GBW、1.1nV/vHz 差分放大器/ADC 驅動器

使用 Analog Devices 的 LTC6409 的參考設計

設計簡介

LTC6409 的典型應用是一款超高速、低失真、差分放大器。其輸入共模范圍包括接地，因此可以對接地參考輸入信號進行直流耦合、電平轉換和轉換以差分驅動 ADC

說明

Typical Application for the LTC6409 is a very high speed, low distortion, differential amplifier. Its input common mode range includes ground, so that a ground-referenced input signal can be DC-coupled, level-shifted, and converted to drive an ADC differentially
