AD-FMCMOTCON2-EBZ
電機驅動系統板設計為 FPGA 夾層卡 (FMC) 板上的完整高性能
伺服系統。 AD-FMCMOTCON2-EBZ 提供完整的電機驅動系統，可展示對高達 48V 和 20A 的三相 PMSM 和感應電機的高效和高動態控制。設計人員可以同時運行兩個電機，每個電機都有獨立的電源。該評估系統集成了高質量電源、可靠的電源、控制和反饋信號隔離、電機電流和電壓信號的精確測量、用于控制信號的高速接口（以允許控制器快速響應）、
工業以太網高速接口、單端霍爾、差分霍爾、編碼器和
旋轉變壓器接口、數字
位置傳感器接口以及通過 FPGA/SoC 接口進行靈活控制。評估套件由控制器板和驅動板組成
說明
-
AD-FMCMOTCON2-EBZ, Motor Drive System Board is designed as a complete high performance servo system on an FPGA Mezzanine Card (FMC) board. AD-FMCMOTCON2-EBZ provides a complete motor drive system that demonstrates efficient and high dynamic control of 3-phase PMSM and induction motors up to 48V and 20A. Designers can run two motors at the same time, with each motor having its separate power supply. The evaluation system incorporates high quality power sources, reliable power, control, & feedback signals isolation, accurate measurement of motor current & voltage signals, high speed interfaces for control signals to allow fast controller response, industrial Ethernet high speed interfaces, single ended Hall, differential Hall, encoder & resolver interfaces, digital position sensors interface, and flexible control with a FPGA/SoC interface. The evaluation kit consists of a controller board and a drive board
主要特色
-
Motor Type
DC Motor|Stepper Motor
