NCP30653ABCKGEVB，高亮度 LED 是一種重要的光源，比傳統光源具有更好的效率和可靠性。高亮度 LED 的改進為創新照明解決方案帶來了潛力，這些解決方案可提供改進的照明體驗，同時減少能源需求。由于 LED 的
正向電壓變化范圍大且 V/I
傳遞函數陡峭，因此需要恒流
驅動器解決方案。適用于由通常用于景觀照明的低壓
交流電源或可用于汽車應用的低壓
直流電源供電的應用，可在寬輸入電壓范圍內工作以驅動一到多個 LED 的串聯串的高效驅動器
說明
-
NCP30653ABCKGEVB, High brightness LEDs are a prominent source of light and have better efficiency and reliability than conventional light sources. Improvements in high brightness LEDs present the potential for creative new lighting solutions that offer an improved lighting experience while reducing energy demand. LEDs require constant current driver solutions due to their wide forward voltage variation and steep V/I transfer function. for applications that are powered from low voltage AC sources typically used in landscape lighting or low voltage DC sources that may be used in automotive applications, high efficiency driver that can operate over wide range of input voltages to drive series strings of one to several LEDs
主要特色
-
Input Voltage
10 to 14 V
-
Output Voltage
3.6|7.2 V
-
Output Current
0.35|0.7|1 A
-
Output Power
1|3|5 W
